Product Description
This listing is for a New HOSHIZAKI Ice Machine Slim Line Modular 340Lb Ice Air Cool KM340MAH
- Dimensions: 22? W x 27-3/8? D x 30- 5/16? H
- Up to 387 lbs of ice produced per 24 hours
- Mount 2 units side-by-side for 2x the ice production
- Slim, 22?W wide profile
- Air-cooled, Slim Line Modular
- Produces crescent ice
- Durable stainless steel exterior
- Compatible bins & dispensers, sold separately in our store
- EverCheck™ alert system
- CycleSaver™ design
- R-404a refrigerant
- Protected by H-GUARD Plus Antimicrobial Agent
- Ambient temperature range: 45 – 100°F
- Water temperature range: 45 – 90°F
- Water pressure: 10 – 113psig
- Voltage range: 104 – 127V
- 9.7 amps (20 Amp Max fuse)
- 5.99 kwh/100 lbs.@ 90/70
- Single phase, 115v/60/1
- ENERGY STAR Qualified
- Three Years: Parts & Labor warranty on entire machine.
- Five Years: Parts & Labor warranty on evaporator.
ELECTRICAL & PLUMBING/KM-201B_H
• 115V/60/1
• 20 amp Max Fuse/HACR Breaker Size
• IcemakerWater Supply Line:Minimum 1/4” Nominal IDCopperWater Tubing or Equivalent
• Icemaker Drain Line:Minimum 3/4” Nominal IDHard Pipe or Equivalent Water-Cooled Model (Lines Must be Independent of Icemaker)
• CondenserWater Supply Line:Minimum 1/4” Nominal ID CopperWater Tubing or Equivalent
• Condenser Drain/Return Line: Minimum 1/4” Nominal ID Hard Pipe (open drain system) or CopperWaterTubing (closed loop system) or Equivalent
